Rear Right CV Drive Shaft For Kia Sorento UM 2.2L Diesel 2.4L Petrol AWD

Rear Right CV Axle Drive Shaft - Automatic All Wheel Drive (AWD)

Built tough to OEM specifications using heat-treated chrome steel, maximizing product life. High-quality Neoprene dust boots and stainless steel clamps helps to prevent contamination. Moly grease for working at varying angles and speeds without friction, at high revolutions.



Vehicle Fitment

• Kia Sorento UM 2.2L Diesel D4HB Turbo AWD (06/2015 - 06/2020)
  Sub Models: AO Edition, Black Edition, GT-Line, Platinum, Si, Si Fleet, SLi & Sport
• Kia Sorento LX UM 2.4L Petrol G4KE AWD (03/2015 - 08/2017)

Sizing and Specifications

• Length (Compressed): 857mm
• Spline Count - Outer/Wheel Side: 30T
• Spline Count - Inner/Diff Side: 25T
• ABS Ring Teeth: 52T

• Hub Nut Style: M24 x 1.5




What's Included

• 1 x CV Shaft

 Our comprehensive range of constant velocity driveshafts is continuing to lead the way in the driveline aftermarket. The excellent performance and quality has resulted in their growing popularity. The range now boasts over 750 individual part numbers, which covers the vast majority of passenger and 4WD applications on Australian roads today. All our CV driveshafts are covered by a 12 month / 20,000 km warranty. Please note: this excludes CV Boots, which are only warranted for 3 months from date of purchase.
