Front CV Joint Drive Shaft for Subaru Forester SJ5 SJG SJD SJ9 Impreza XV GT7

CV Axle Drive Shaft - Front Left or RightHand Side CVT Manual AWD

***Please check check outer spline count and shaft length outer/wheel side of your original shaft***

Built tough to OEM specifications using heat-treated chrome steel; maximizing product life. High-quality Neoprene dust boots and stainless steel clamps helps to prevent contamination. Moly grease for working at varying angles and speeds without friction, at high revolutions.

Vehicle Fitment

• Subaru Forester SJ S13 Chassis: SJ5 SJG SJD SJ9 AWD MT CVT (01/2013 - 09/2018) Please check check outer spline count and shaft length outer/wheel
  Includes Sub-models 2.0i, 2.0i-L, 2.0XT, tS Special Edition, 2.0XT, 2.0D, 2.0D-L, 2.0D-S, 2.5i, 2.5i-L, 2.5i-S, Fleet Edition, X Limited Edition

• Subaru XV GT G24 Chassis: GT7 AWD CVT (05/2017 - 12/2022) Shaft length 807mm
  Includes Sub-models 2.0i, 2.0i-L, 2.0i-S, 20i+, S-Edition
• Subaru Impreza GT G14 Chassis: GT7 AWD CVT (09/2016 - 10/2023) Shaft length 807mm
  Includes Sub-models 2.0i, 2.0i-L, 2.0i-S

Sizing and Specifications

• Length (Compressed): 807mm
• Spline Count - Outer/Wheel Side: 27T
• Spline Count - Inner/Diff Side: 25T
• Inboard Joint Type: Tripod
• Outboard Joint Type: Ball
• Hub Nut Style: M22 x 1.5
• Spline Shaft Length - Outer: 80.5mm

What's Included

• 1 x CV Shaft

 Our comprehensive range of constant velocity driveshafts is continuing to lead the way in the driveline aftermarket. The excellent performance and quality has resulted in their growing popularity. The range now boasts over 750 individual part numbers, which covers the vast majority of passenger and 4WD applications on Australian roads today. All our CV driveshafts are covered by a 12 month / 20,000 km warranty. Please note: this excludes CV Boots, which are only warranted for 3 months from date of purchase.
