Left CV Drive Shaft for Suzuki Alto GF 1.0L 09~15, Celerio LF 1.0L 15~18 Manual

Brand New Left CV Drive Shaft

***Suits Manual Transmission | Please Check OE Before Fitting***

Built tough to OEM specifications using heat-treated chrome steel for maximum product life. High-quality Neoprene dust boots and stainless steel clamps help prevent contamination. Packed with moly grease to perform at varying angles and speeds without friction, even at high revolutions.

Vehicle Fitment

• Suzuki Alto GF FC31S (07/2009~01/2015) 1.0L Petrol K10BN
• Suzuki Celerio LF LFE42S (02/2015~02/2018) 1.0L Petrol K10B

⚠️ Important Notes for You:
We strongly advise using the Australian Number Plate lookup to confirm fitment.

Sizing and Specifications

• ABS: Yes
• Length (Compressed): 660 mm
• Spline Count - Outer/Wheel Side: 23
• Spline Count - Inner/Diff Side: 22
• Inboard Joint Type: Tripod
• Outboard Joint Type: Ball
• ABS Ring Teeth: 43
• Drive Shaft Seal (Inner) ID: 40 mm
• Hub Nut: M18 x 1.5

What's Included

• 1 x CV Shaft

All components include a 12 month/20,000km warranty and support from our specialist team.
