Starter Motor for Holden H-Series Belmont, Kingswood, Monaro, One-Tonner, Panel Van, Premier, Special, Standard, Statesman Custom, Utility EH HD HG HK HR HJ HQ HX HT HZ WB / Calais VK / Commodore VB VC VH VK / Torana LC LJ LH LX UC

One Brand New Starter Motor

Bosch Style Unit

We are proud to offer top-tier starter motors that set the standard in automotive excellence. Our products are crafted in accordance with stringent international quality standards (ISO/TS16949), ensuring reliability and superior performance for a wide range of vehicles.

Vehicle Fitment

• Holden Belmont HK HT HG HJ HQ HX 2.6L 161 / 2.8L 173 / 3.0L 186 / 3.3L 202 (02/1968 - 09/1977)
  Includes Sub-models Utility, Panel Van, Sandman
• Holden Calais VK 3.3L 202 Black LL9 (03/1984 - 02/1986)
  Includes Sub-models
• Holden Commodore VB VC VH VK 2.8L 173 LD1 / 3.3L 202 (11/1978 - 03/1986)
  Includes Sub-models L, SL, SL/X, SL/E, Vacationer, Executive, Berlina
• Holden Kingswood HK HT HG HQ HJ HX HZ WB 2.6L 161 HC LC / 2.8L 173 HC LC / 3.0L 186 S HC LC / 3.3L 202 RED BLUE (02/1968 - 07/1985)
  Includes Sub-models Utility, Sandman, Vacationer, Vacationer II, Deluxe, 50th Anniversary, Ambulance, Panel Van, SL, Outback Package, VIC Police Package
• Holden Monaro HK HT HG HQ HJ 2.6L 161 / 2.8L 173 / 3.0L 186 / 3.3L 202 (07/1968 - 07/1976)
  Includes Sub-models GTS, LS
• Holden One Tonner HQ HJ HX HZ WB 2.8L 173 / 3.3L 202 (1971 - 07/1985)
  Includes Sub-models 1000KG 2M, Ambulance
• Holden Panel Van EH HD HR HJ HX HZ WB 2.4L 149 / 2.6L 161 / 2.8L 173 / 2.9L 179 / 3.0L 186 / 3.3L 202 (08/1963 - 07/1985)
  Includes Sub-models Ambulance, Sandman
• Holden Premier EH HD HR HK HT HQ HJ HX 2.9L 179 / 3.0L 186 / 3.3L 202 (08/1963 - 04/1980)
  Includes Sub-models
• Holden Special EH HD HR 2.4L 149 / 2.6L 161 / 2.9L 179 / 3.0L 186 (08/1963 - 02/1968)
  Includes Sub-models
• Holden Standard EH HD HR 2.4L 149 / 2.6L 161 / 2.9L 179 / 3.0L 186 (08/1963 - 02/1968)
  Includes Sub-models
• Holden Statesman Custom HQ 3.3L 202 RED HC LC (07/1971 - 10/1974)
  Includes Sub-models Custom
• Holden Torana LC LJ LH LX UC  2.6L 161 / 2.8L 173 / 3.0L 186 / 3.3L 202 (10/1969 - 1979)
  Includes Sub-models S, SS, SL, SL/R, GTR, GTR XU1, XU1
• Holden Utility EH HD HR HJ HX HZ WB 2.4L 149 / 2.6L 161 / 2.8L 173 / 2.9L 179 / 3.0L 186 / 3.3L 202 (08/1963 - 07/1985)
  Includes Sub-models Sandman, Big Country



Specifications and Sizing

• Voltage: 12V

• KW: 1.4KW
• Rotation Direction: Clockwise
• Pinion Teeth: 9
• Pinion at Rest: 6mm
• Pinion Diameter: 25mm
• Overall Length: 240mm
• Mounting Bolt Centre-Centre(s): 105mm
• Mounting Hole Diameter: 10mm

• Flange Diameter: 82mm
• Nose Cone Length: 41mm

What's Included

• 1 x Starter Motor

All our parts come with a 12 month/20,000km warranty. They are backed up with a professional customer service team that has been in the industry for over 100 years. We are the wheel end experts. Our customer service team will be there to support you throughout the entire process. From questions you have pre-purchase to follow up support post purchase. Make the right decision and buy with a company that has a proven track record in service and supply.
