Starter Motor for Hyundai i45 YF, iLoad iMAX TQ, iX35 LM, Santa Fe CM DM, TM Sonata LF NF / Kia Cerato TD, Magentis MG, Optima JF TF, Rondo UN, Sorento XM UM, Sportage SL QL - 2.0L 2.4L Engines

One Brand New Starter Motor

11 Tooth Pinion

We are proud to offer top-tier starter motors that set the standard in automotive excellence. Our products are crafted in accordance with stringent international quality standards (ISO/TS16949), ensuring reliability and superior performance for a wide range of vehicles.



Vehicle Fitment

• Hyundai i45 YF 2.0L G4KD / 2.4L G4KJ FWD (05/2010 - 01/2013)
  Includes Sub-models Active, Elite, Premium

• Hyundai iLoad iMAX inc. H1 iMAX TQ 2.4L G4KG RWD (02/2008 - 04/2018)
  Includes Sub-models iLoad, iMax, H1 iMax, 3S Liftback
• Hyundai iX35 LM 2.0L G4KD FWD / 2.4L G4KE G4KJ AWD (02/2010 - 06/2015)
  Includes Sub-models Active, Elite, SE, Highlander
• Hyundai Santa Fe CM DM TM 2.4L G4KE G4KJ 4WD AWD (11/2009 - 10/2019)
  Includes Sub-models Active, Elite, Limited
• Hyundai Sonata LF NF 2.4L G4KC G4KJ FWD (06/2005 - 10/2020)
  Includes Sub-models SLX, Elite, Active
• Kia Cerato TD 2.0L G4KD FWD (10/2008 - 09/2013)
  Includes Sub-models Limited Edition, KOUP, KOUP Si, KOUP SLS, S, Si, SLi, SiR, LX
• Kia Magentis MG 2.4L G4KC G4KE G6EA FWD (08/2006 - 03/2010)
  Includes Sub-models EX, EX-L, LX
• Kia Optima JF TF 2.0L G4KH / 2.4L G4KJ FWD (01/2011 - 10/2020)
  Includes Sub-models GT, GT NAV, Si, SLi, Platinum
• Kia Rondo UN 2.0L G4KA FWD (04/2008 - 09/2010)
  Includes Sub-models EX, EX Limited, LX, Si, SLi
• Kia Sorento XM UM 2.4L G4KE G4KJ FWD AWD (11/2009 - 2018)
  Includes Sub-models Si
• Kia Sportage SL 2.0L G4KD / SL QL 2.4L G4KE G4KJ FWD AWD (05/2010 - 09/2021) Recommended to Check OE Part Number
  Includes Sub-models Si, Si Premium, SLi, Platinum, GT-Line, GT-Line Grey Leather, EX, LTD, Urban LX+



Specifications and Sizing

• Voltage : 12V

• KW: 1.2
• Rotation Direction: Clockwise
• Pinion Teeth: 11T
• Pinion at Rest: 30mm
• Pinion Diameter: 34mm
• Overall Length: 210mm
• Mounting Bolt Centre-Centre(s): 94mm
• Mounting Hole Diameter: M8 x 1.25

• Flange Diameter: 70mm
• Nose Cone Length: 68mm

What's Included

• 1 x Starter Motor

All our parts come with a 12 month/20,000km warranty. They are backed up with a professional customer service team that has been in the industry for over 100 years. We are the wheel end experts. Our customer service team will be there to support you throughout the entire process. From questions you have pre-purchase to follow up support post purchase. Make the right decision and buy with a company that has a proven track record in service and supply.
